Description
| MODEL | CBD30X | CBD35X |
|---|---|---|
| CAPACITY | 3000kg | 3500kg |
| LOAD CENTRE | 600mm | 600mm |
| LIFTING HEIGHT | 115mm | 115mm |
| LOWERED HEIGHT | 85mm | 85mm |
| FORK LENGTH | 1150mm/1220mm | 1150mm/1220mm |
| OUTSIDE WIDTH OF FORKS | 560mm/685mm | 560mm/685mm |
| MINIMUM GROUND CLEARANCE | 30mm | 30mm |
| TRAVEL SPEED: LADEN/ UNLADEN | 4km/h / 5km/h | 4km/h / 5km/h |
| LIFTING SPEED: LADEN/ UNLADEN | 10mm/s / 13mm/s | 10mm/s / 13mm/s |
| LOWER SPEED: LADEN/ UNLADEN | 14mm/s / 10mm/s | 14mm/s / 10mm/s |
| BATTERY VOLTAGE/ CAPACITY | 24V/ 165AH | 24V/ 165AH |
| WHEEL BASE | 1380mm / 1450mm | 1380mm / 1450mm |
| MINIMUM TURNING RADIUS | 1540mm / 1610mm | 1540mm / 1610mm |
| OVERALL LENGTH | 1860mm | 1860mm |
| OVERALL WIDTH | 2055mm / 2125mm | 2055mm / 2125mm |
| OVERALL HEIGHT | 1215mm | 1215mm |
| NET WEIGHT | 460kg | 460kg |
